TF125
Your Reliable Working Partner On Tough Terrains
The TF125, powered by a tough and reliable power-reed-valve air-cooled 2-stroke engine, is a bike that's tailor-equipped to
fully meet the requirements of a run-about vehicle in versatile tough-work use. It topped off by special protectors, extended
fenders, both right-and-left sidestands, big luggage carrier and wide-tread block pattern tires ready for rough road riding.
Features
Functional engine guard bar and plate
Wide-tread block pattern tires
Large flat rear carrier and strage box
Heavy-duty headlight protector
Suzuki-rv-125-service-manual.pdf, suzuki-rv125-service-manual.rar, suzuki-rv125-2003-2006-service-manual.rar.
Suzuki Tf125 Service Manual Online
Specifications
Suzuki Tf 125 Service Manual
- Engine Type
- 2-stroke, 1-cylinder, air-cooled
- Engine Displacement
- 123 cm3 (7.5 cu. in)
- Bore x Stroke
- 56.0 mm x 50.0 mm (2.2 in x 2.0 in)
- Transmission
- 6-speed constant mesh
- Overall Length
- 2,170 mm (85.4 in)
- Overall Width
- 935 mm (36.8 in)
- Overall Height
- 1,150 mm (45.3 in)
- Wheelbase
- 1,335 mm (52.6 in)
- Ground Clearance
- 250 mm ( 9.8 in)
- Seat Height
- 835 mm (32.9 in)
Suzuki Tf125 Service Manual Free
- Curb Mass
- 102 kg (225 lbs)
- Suspension Front
- Telescopic, coil spring, oil damped
- Rear
- Swingarm type, coil spring, oil damped
- Brakes Front
- Drum
- Rear
- Drum
- Tires Front
- 2.75-21 4PR, tube type
- Rear
- 4.10-18 4PR, tube type
- Fuel Tank Capacity
- 13.0 L (3.4/2.9 US/Imp gal)
